General Specifications |
Power supply | : | 100_240 VAC, ~50/60 Hz |
Total speaker output power (Max. @THD 1%) | : | 80 W |
Soundbar output power (Max. @THD 1%) | : | 2 x 40 W |
Soundbar Transducer | : | 2 racetrack drivers |
Soundbar standby power | : | < 0.5 W |
• Operating temperature | : | 0°–45° C |
HDMI Video Output (with Audio Return Channel) | : | 1 |
Audio Specifications |
Frequency response | : | 70 Hz - 20 KHz |
Audio input | : | 1 Optical, Bluetooth, USB (USB playback is available in the US version. In other versions, USB is for Service only.) |
Dimension Specifications |
Soundbar Dimensions (L x H x W) | : | Yes |
614 x 58 x 90 (mm) / 24.17" x 2.28" x 3.54" | : | Yes |
Soundbar Weight | : | 1.61 kg |
Packing dimensions (L x H x W) | : | 855 x 125 x 145 mm |
Packing weight (Gross weight) | : | 2.6kg |
Control and Connection Specifications |
Ports (USB) | : | Type A |
USB Ratings | : | 5 V DC / 0.5 A |
Supported file formats | : | mp3, wav |
MP3 Codecs | : | MPEG 1 Layer 2/3, MPEG 2 Layer 3, MPEG 2.5 Layer 3 |
MP3 sampling rate | : | 16–48 kHz |
MP3 Bitrates | : | 80–320 kbps |
WAV sampling rate | : | 16–48 kHz |
WAV Bitrates | : | up to 3,000 kbps |
Bluetooth version | : | 4.2 |
Bluetooth profile | : | A2DP V1.3, AVRCP V1.5 |
Bluetooth frequency range | : | 2,402–2,480 MHz |
Max transmit power. Bluetooth | : | <10 dBm (EIRP) |
Modulation Type | : | GFSK, π/4 DQPSK, 8DPSK |
