JBL MA7100HP
7.2-channel 8K High Performance AV Receiver
| HDMI eARC | : | yes |
| HDMI Audio Return Channel | : | yes |
| 8K HDMI input connectors (HDMI 2.1, HDCP 2.3 up to 8K/60Hz, 4K/120Hz) | : | 3 |
| HDMI 2.1 enhanced gaming features | : | Gaming-VRR, ALLM, QFT, HFR (4K@120Hz) |
| HDR 10+, Dolby Vision | : | Yes , Yes |
| File format | : | MP3 / MPEG-4 AAC |
| Pure Analog | : | yes |
| EZ Set EQ | : | yes |
| Front channel bi-amp | : | yes |
| Digital signal processing | : | up to 24-bit/192kHz |
| Mains voltage | : | 110 – 240V, 50–60Hz |
| Max. power consumption | : | 700W |
| Standby power consumption | : | <0.5W |
| Channels | : | 7.2 |
| FTC Rated Output Power (20Hz– 20kHz, 2 channels driven, 1% THD max, 8Ω) | : | 125W |
| Rated Power @ 8Ω (20Hz – 20kHz, 2 channels driven, 0.5% THD max) | : | 125 W RMS |
| Rated Power @ 4Ω (20Hz – 20kHz, 2 channels driven, 0.5% THD max) | : | 175 W RMS |
| Dimensions incl. feet and speaker terminals (H x W x D) | : | 5.3" x 17.0" x 15.6" (135.0mm x 432.0mm x 396.4mm) |
| Weight | : | 16.4lb (7.4kg) |
| HDMI Input/Output | : | 6/ 2 |
| Wi-Fi | : | Yes (2.4/5GHz) |
| Bluetooth receiver | : | Yes (v5.3, Low Energy, APTX HD, APTX Adaptive) |
| Bluetooth transmit | : | Yes (2.4/5GHz) |
| Digital Audio Input | : | 1 Coax, 1 Optical, 1 USB |
| Stereo analog input | : | 2 single-ended RCA (line level), 1 Moving Magnet Phono input + Ground |
| Pre-Out (single ended RCA) | : | Stereo Zone 2, Subwoofer 1, Subwoofer 2 |
| Ethernet | : | RJ45 Gigabit, WiFi Onboard |
