General Specifications |
Transducer |
: |
53 x 93mm woofer, 20mm tweeter |
Output power |
: |
30W RMS for woofer, 10W RMS for tweeter |
Frequency response |
: |
60Hz - 20kHz |
Signal-to-noise ratio |
: |
> 80dB |
Dimension Specifications |
Product dimensions(W x H x D) |
: |
223 x 97 x 94mm/8.8 x 3.8 x 3.7" |
Net weight |
: |
1.0kg/2.2lbs, Packaging dimensions(W x H x D):257 x 130 x 120 mm/ 10.1 x 5.1 x 4.7" |
Gross weight |
: |
1.7kg/3.7lbs |
Control and Connection Specifications |
USB ports |
: |
USB Type A x1, USB Type C x1 |
Wireless network |
: |
IEEE 802.11 a/b/g/n/ac/ax(2.4GHz/5GHz) |
Bluetooth version |
: |
5.3 |
Bluetooth profile |
: |
AVRCP 1.5 and A2DP1.3 |
Bluetooth transmitter frequency range |
: |
2.4GHz-2.4835GHz |
Bluetooth transmitter power |
: |
<13dBm (EIRP) |
Bluetooth transmitter modulation |
: |
GFSK, π/4-DQPSK, 8DPSK |
5G Wi-Fi transmitter frequency range |
: |
5.15-5.35GHz, 5.470-5.725GHz, 5.725-5.825GHz |
5G Wi-Fi transmitter power |
: |
<23dBm |
5G Wi-Fi modulation |
: |
OFDM (BPSK, QPSK, 16QAM, 64QAM, 256QAM, 1024QAM) |
5G Wi-Fi network compatibility |
: |
802.11a/n/ac/ax |
2.4G Wi-Fi transmitter frequency range |
: |
2.4GHz-2.4835GHz |
2.4G Wi-Fi transmitter power |
: |
<20dBm |
2.4G Wi-Fi modulation |
: |
DSSS (DBPSK, DQPSK, CCK), OFDM (BPSK, QPSK, 16QAM, 64QAM, 256QAM, 1024QAM) |
2.4G Wi-Fi network compatibility |
: |
802.11b/g/n/ax |
Battery |
Battery type |
: |
Li-ion polymer 52Wh
(equivalent to 3.69V/14100mAh) |
Battery charge time |
: |
6 hours (5V/3A) |
Music play time |
: |
up to 20hours(dependent on volume level and audio content) |
Cable type |
: |
USB Charging cable |
Cable length |
: |
1200mm/ 47.2" |
USB charge out |
: |
5V/2A(maximum) |
Maximum operation temperature |
: |
45°C |
